NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
36
SECTION 6
ELECTRICAL PARTS LIST
1-676-330-11 AC SW BOARD
***********
< CONNECTOR >
0CN909 1-769-745-21 LEAD (WITH CONNECTOR) (2 CORE)
< SWITCH >
0S901 1-572-267-51 SWITCH, PUSH (AC POWER)(1 KEY)(POWER)
************************************************************
A-4428-524-A DISPLAY BOARD, COMPLETE
***********************
4-226-964-01 HOLDER (FL)
* 4-921-941-01 CUSHION (FL)
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C801 1-128-131-11 ELECT 22uF 20.00% 50V
C802 1-128-131-11 ELECT 22uF 20.00% 50V
C803 1-162-294-31 CERAMIC 0.001uF 10% 50V
C804 1-124-584-00 ELECT 100uF 20% 10V
C805 1-124-584-00 ELECT 100uF 20% 10V
C806 1-128-131-11 ELECT 22uF 20.00% 50V
C807 1-164-159-11 CERAMIC 0.1uF 50V
C808 1-164-159-11 CERAMIC 0.1uF 50V
C811 1-162-213-31 CERAMIC 39PF 5.00% 50V
C840 1-162-282-31 CERAMIC 100PF 10% 50V
C841 1-162-282-31 CERAMIC 100PF 10% 50V
C842 1-162-288-31 CERAMIC 330PF 10% 50V
C843 1-162-288-31 CERAMIC 330PF 10% 50V
< CONNECTOR >
CN801 1-784-737-11 CONNECTOR, FFC 15P
CN802 1-770-480-11 SOCKET, CONNECTOR PIN 4P
< FILTER >
FL801 1-517-950-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC801 8-749-013-92 IC GP1UC7X
IC802 8-759-596-83 IC MSM9202-05
IC803 8-759-596-83 IC MSM9202-05
< TRANSISTOR >
Q801 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q802 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q803 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q804 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q805 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q806 8-729-029-66 TRANSISTOR DTC114ESA-TP
< RESISTOR >
R801 1-249-437-11 CARBON 47K 5% 1/4W
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-437-11 CARBON 47K 5% 1/4W
R804 1-249-437-11 CARBON 47K 5% 1/4W
R805 1-249-437-11 CARBON 47K 5% 1/4W
R806 1-249-437-11 CARBON 47K 5% 1/4W
R807 1-249-417-11 CARBON 1K 5% 1/4W F
R808 1-247-807-31 CARBON 100 5% 1/4W
R809 1-247-843-11 CARBON 3.3K 5% 1/4W
R811 1-249-425-11 CARBON 4.7K 5% 1/4W F
R812 1-249-427-11 CARBON 6.8K 5% 1/4W F
R813 1-249-429-11 CARBON 10K 5% 1/4W
R814 1-249-433-11 CARBON 22K 5% 1/4W
R821 1-249-425-11 CARBON 4.7K 5% 1/4W F
R822 1-249-427-11 CARBON 6.8K 5% 1/4W F
R823 1-249-429-11 CARBON 10K 5% 1/4W
R824 1-249-433-11 CARBON 22K 5% 1/4W
R840 1-247-807-31 CARBON 100 5% 1/4W
R841 1-247-807-31 CARBON 100 5% 1/4W
R842 1-247-807-31 CARBON 100 5% 1/4W
R843 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S801 1-762-875-21 SWITCH, KEYBOARD (DAB)
S802 1-762-875-21 SWITCH, KEYBOARD (EON)
S803 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S804 1-762-875-21 SWITCH, KEYBOARD (DISPLAY MODE)
S805 1-762-875-21 SWITCH, KEYBOARD (MONO/ST)
S806 1-762-875-21 SWITCH, KEYBOARD (FM)
S807 1-762-875-21 SWITCH, KEYBOARD (AM)
S808 1-762-875-21 SWITCH, KEYBOARD (MEMORY)
S809 1-762-875-21 SWITCH, KEYBOARD (CHARACTER)
************************************************************
AC SW
DISPLAY
To Next Page
