Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
42
< VARIABLE RESISTOR >
RV201 1-241-764-11 RES, ADJ, CARBON 10K
RV202 1-241-765-11 RES, ADJ, CARBON 22K
RV203 1-241-764-11 RES, ADJ, CARBON 10K
RV301 1-241-767-21 RES, ADJ, CARBON 100K
< RELAY >
RY201 1-515-614-11 RELAY
RY501 1-515-614-11 RELAY
< ENCAPSULATED >
T201 1-235-126-00 ENCAPSULATED COMPONENT
< TERMINAL >
TM201 1-537-488-11 TERMINAL BOARD (ANT) (ANTENNA)
< TEST PIN >
* TP201 1-565-513-11 PIN, CONNECTOR 2P
< VIBRATOR >
X201 1-760-549-31 VIBRATOR, CRYSTAL 4.5MHz
X401 1-579-900-21 VIBRATOR, CRYSTAL 4.332MHz
X501 1-781-747-11 OSCILLATOR, CRYSTAL 49.152MHz
X601 1-579-175-11 VIBRATOR, CERAMIC 10MHz
************************************************************
A-4428-525-A POWER BOARD, COMPLETE
**********************
* 4-363-146-71 HEAT SINK, V.OUT
< CAPACITOR >
0C901 1-113-925-11 CERAMIC 0.01uF 20.00% 250V
0C902 1-110-677-11 MYLAR 0.047uF 20.00% 275V
C903 1-164-096-11 CERAMIC 0.01uF 50V
C904 1-164-096-11 CERAMIC 0.01uF 50V
C905 1-164-096-11 CERAMIC 0.01uF 50V
C906 1-164-096-11 CERAMIC 0.01uF 50V
C907 1-119-806-21 ELECT 3300uF 20.00% 25V
C908 1-119-800-11 ELECT 100uF 20.00% 16V
C909 1-164-159-11 CERAMIC 0.1uF 50V
C910 1-119-800-11 ELECT 100uF 20.00% 16V
C911 1-119-800-11 ELECT 100uF 20.00% 16V
C912 1-119-800-11 ELECT 100uF 20.00% 16V
C913 1-119-806-21 ELECT 3300uF 20.00% 25V
C914 1-119-800-11 ELECT 100uF 20.00% 16V
C915 1-119-795-21 ELECT 3300uF 20.00% 16V
C916 1-119-800-11 ELECT 100uF 20.00% 16V
C918 1-119-820-11 ELECT 1uF 20% 50V
C919 1-119-817-11 ELECT 0.22uF 20.00% 50V
C920 1-119-824-11 ELECT MELF 10uF 20% 50V
C921 1-164-159-11 CERAMIC 0.1uF 50V
C922 1-164-159-11 CERAMIC 0.1uF 50V
C923 1-161-494-00 CERAMIC 0.022uF 25V
C924 1-161-494-00 CERAMIC 0.022uF 25V
C925 1-128-874-51 ELECT 330uF 20% 63V
C926 1-128-860-11 ELECT 47uF 20% 50V
C927 1-128-860-11 ELECT 47uF 20% 50V
C928 1-119-800-11 ELECT 100uF 20.00% 16V
C929 1-119-806-21 ELECT 3300uF 20.00% 25V
< CONNECTOR >
CN902 1-766-202-11 SOCKET, CONNECTOR PIN 14P
CN903 1-766-201-11 SOCKET, CONNECTOR PIN 11P
CN904 1-691-769-21 PLUG (MICRO CONNECTOR) 7P
CN905 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CN906 1-564-321-00 PIN, CONNECTOR 2P
* CN907 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
CN908 1-564-321-00 PIN, CONNECTOR 2P
< DIODE >
D901 8-719-210-21 DIODE 11EQS04-TA2B
D902 8-719-210-21 DIODE 11EQS04-TA2B
D903 8-719-210-21 DIODE 11EQS04-TA2B
D904 8-719-210-21 DIODE 11EQS04-TA2B
D905 8-719-510-53 DIODE RBV-402-01
D906 8-719-510-53 DIODE RBV-402-01
D909 8-719-200-77 DIODE 10E2N-TA2B
D910 8-719-200-77 DIODE 10E2N-TA2B
D911 8-719-024-99 DIODE 11ES2-NTA2B
D912 8-719-118-66 DIODE RD6.2F-T7B2
D913 8-719-986-70 DIODE HZS36-1LTA
D914 8-719-911-19 DIODE 1SS133T-72
D919 8-719-911-19 DIODE 1SS133T-72
< GROUND >
EB1 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC901 8-759-394-35 IC BA12T
IC902 8-749-920-58 IC SI-3090CA
IC903 8-759-245-86 IC M5F7912L
IC905 8-759-333-83 IC NJM2103D
IC906 8-759-450-47 IC BA05T
< TRANSISTOR >
Q901 8-729-030-02 TRANSISTOR DTC144ESA-TP
Q902 8-729-141-83 TRANSISTOR 2SB1375
Q903 8-729-141-83 TRANSISTOR 2SB1375
Q904 8-729-030-02 TRANSISTOR DTC144ESA-TP
Q905 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q906 8-729-029-56 TRANSISTOR DTA144ESA-TP
Q907 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q908 8-729-141-83 TRANSISTOR 2SB1375
Q909 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q910 8-729-209-15 TRANSISTOR 2SD2012
Q911 8-729-030-02 TRANSISTOR DTC144ESA-TP
Q912 8-729-140-97 TRANSISTOR 2SB734-T-34
Q913 8-729-119-76 TRANSISTOR 2SA1115TP-EF
< RESISTOR >
R901 1-249-421-11 CARBON 2.2K 5% 1/4W F
R903 1-249-421-11 CARBON 2.2K 5% 1/4W F
R904 1-249-417-11 CARBON 1K 5% 1/4W F
R905 1-249-421-11 CARBON 2.2K 5% 1/4W F
R906 1-249-417-11 CARBON 1K 5% 1/4W F
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
MAIN POWER
