9.9 Wiring diagram 4400 & 4500 series 40"
19431_402_130301.eps
131130
WIRING DIAGRAM 40" (4400&4500 series)
Board Level Repair
Component Level Repair
Only for authorized workshops
See note in Chapter 6 about cable position numbers
KEYBOARD CONTROL (1057)
E
LOUDSPEAKERLOUDSPEAKER
(1186)(1186)
IR/LED BOARD
(1056)
J
LOUDSPEAKER
(1186)
LOUDSPEAKERLOUDSPEAKER
(1185)(1185)
LOUDSPEAKER
(1185)
SSB
(1053)
B
LN
CN9901
MAIN POWER SUPPLY
(1054)
A
HDMI
USB 2
USB 1
CI
NETWORK
TV ANTENNA
DIGITAL
AUDIO OUT
LR
CVBS/Y Pb
Pr
SERV.U
AUDIO IN
DV I
HDMI 1
ARC
HDMI 2
SCART
(RGB/CVBS)
WIFI
MODULE
LED DRIVER
(1055)
AD
CN016
5P
12P
CN8101
12P
CN9102
10P
CN8103
TO PANEL
TO PANEL
TO PANEL
CN8102
10P
38P
CN408
5P
WIFI01
5P
CN4250
12P
CN700
13P
CN9101
4P
CN601
CN201
6P
CN401
13P
WiFi Antenna
ECN700
ECN408
ECN601
ECN4250
ECN401
ECN8102
ECN9102
