Philips TPM10.1E LA - Wiring Diagram 3200 Series 39

EN 86TPM10.1E LA 9.
Block Diagrams
2014-Jul-18
back to
div.table
9.22 Wiring diagram 3200 series 39"
19433_400_130509.eps
130509
WIRING DIAGRAM 39" (3200 series)
Board Level Repair
Component Level Repair
Only for authorized workshops
See note in Chapter 6 about cable position numbers
KEYBOARD CONTROL (1057)
E
LOUDSPEAKERLOUDSPEAKER
(1186)(1186)
J
LOUDSPEAKER
(1186)
LOUDSPEAKERLOUDSPEAKER
(1185)(1185)
LOUDSPEAKER
(1185)
SSB
(1053)
B
HDMI
USB 2
USB 1
CI
NETWORK
TV ANTENNA
DIGITAL
AUDIO OUT
LR
CVBS/Y Pb
Pr
SERV.U
AUDIO IN
DV I
HDMI 1
ARC
SCART
(RGB/CVBS)
12P
IR/LED BOARD
(1056)
6P
3P
13P
4P
LN
CN9902
MAIN POWER SUPPLY
(1054)
A
13P
12P
CN8501
TO PANEL
TO PANEL
CN9101
CN601
CN401
38P
CN408
CN700
CN201
CN016
ECN700
ECN408
ECN401
ECN601
