Philips VES2.2E LA - Wiring Diagram 3000 Series 39

EN 32VES2.2E LA 9.
Block Diagrams
2013-Jul-19
back to
div. table
9.2 Wiring diagram 3000 series 39"
19421_400_130424.eps
130424
Board Level Repair
Component Level Repair
Only for authorized workshops
WIRING DIAGRAM 39" (3000 series)
MAIN POWER SUPPLY
(M3)
A
IR/LED BOARD
(M6)
J
CN27
CVBS
R/L Audio
USB
CI
5P
2P
12P
CN500
PL100
5P
4P
20P
CN12
CN15
CN3
SCART
(RGB/CVBS)
VGA
SPDF OUT
TV ANTENNA
SSB
(M2)
B
CN26
6P
M7
to Panel
M5M5
