Phoenix Contact Basicline 2 Series User Manual

Technical appendix
3799_en_D PHOENIX CONTACT 23/36
A Technical appendix
A 1 Technical data
General data
Overall, dimensions (width x height x depth)
*
no display (BL2 BPC 1000, BL2 BPC 2000)
no display (BL2 BPC 7000)
with 12-in. display
with 15-in. display
with 17-in. display
162 x 146 x 49 mm
186 x 146 x 49 mm
365 x 282 x 84 mm
410 x 309 x 86 mm
452 x 356.5 x 86 mm
Ambient temperature (operation) 0 … 50°C
Ambient temperature (storage/transport) -40 … 70°C
Permissible humidity (relative)
If equipped with wireless mini PCIe card option
5% … 95%, non-condensing
10% … 80%, non-condensing
Weight (BL2 BPC 1000, BL2 BPC 2000)
with no display
with 12-in. display
with 15-in. display
with 17-in. display
1.5 kg
4.1 kg
5.7 kg
7.1 kg
Weight (BL2 BPC 7000)
with no display
with 12-in. display
with 15-in. display
with 17-in. display
2.0 kg
4.6 kg
6.2 kg
7.6 kg
Degree of protection
BL2 BPC ...
BL2 PPC ...
IP20
IP65 in front, IP20 at back
Mounting
BL2 BPC ...
BL2 PPC ...
Wall or DIN rail
Panel mount
LED indicators Power, SATA, Run, Error
*
Dimensions are overall, including bezel
Electrical data
Power supply, nominal 24 V DC ±20%
Type of connection Removable COMBICON screw-type
Conductor size 0.2 … 2.5 mm² (24 … 12 AWG)
Torque, wire clamping screw 0.5 … 0.6 Nm
RTC battery, typical life BR2032, 5 years
