Phoenix Contact Basicline 2 Series User Manual

BL2 ...1000/2000/7000
26/36
PHOENIX CONTACT 3799_en_D
Display – 12 in.
Display backlighting type LED
Screen size, diagonal 307 mm (12.1 in.)
Screen size, horizontal x vertical 246 x 185 mm
Resolution 1024 x 768
Type Resistive touch screen
Brightness 500 Cd/m²
Number of colors 16.2 million
Backlight life, minimum 50000 h
Contrast ratio 700:1
View angle, horizontal/vertical (CR=10), typ. 80°/65°
Installation cutout dimensions (width x height) 334.0 x 253.0 mm
Outside bezel dimensions (width x height x depth) 365 x 282 x 83 mm
Display – 15 in.
Display backlighting type LED
Screen size, diagonal 378 mm (14.9 in.)
Screen size, horizontal x vertical 304 x 228 mm
Resolution 1024 x 768
Type Resistive touch screen
Brightness 300 Cd/m²
Number of colors 16.2 million
Backlight life, minimum 50000 h
Contrast ratio 700:1
View angle, horizontal/vertical (CR=10), typ. 80°/70°
Installation cutout dimensions (width x height) 386.6 x 285.6 mm
Outside bezel dimensions (width x height x depth) 410 x 309 x 86 mm
Display – 17 in.
Display backlighting type LED
Screen size, diagonal 430 mm (16.93 in.)
Screen size, horizontal x vertical 338 x 270 mm
Resolution 1280 x 1024
Type Resistive touch screen
Brightness 350 Cd/m²
Number of colors 16.7 million
Backlight life, minimum 50000 h
Contrast ratio 1000:1
View angle, horizontal/vertical (CR=10), typ. 85°/80°
Installation cutout dimensions (width x height) 424.0 x 329.5 mm
Outside bezel dimensions (width x height x depth) 452 x 357 x 86 mm
Mechanical tests
Shock test according to IEC 60068-2-27 15g with 11 ms impulse
Vibration resistance according to EN 60068-2-6 1g
