Technical data
108147_en_00 PHOENIX CONTACT 33 / 44
Connection data
main circuit IN+
Connection method Push-in connection
Stripping length 15 mm
Conductor cross section solid 0.2 mm² ... 10 mm²
AWG conductor cross section 15 ... 8
Conductor cross section flexible, with ferrule, with plastic
sleeve
0.25 mm² ... 4 mm²
Conductor cross section flexible, with ferrule, w/o plastic
sleeve
0.25 mm² ... 6 mm²
Main circuit IN-
Connection method Push-in connection
Stripping length 10 mm
Conductor cross section solid 0.2 mm² ... 2.5 mm²
AWG conductor cross section 24 ... 12
Conductor cross section flexible, with ferrule, with plastic
sleeve
0.25 mm² ... 1.5 mm²
Conductor cross section flexible, with ferrule, w/o plastic
sleeve
0.25 mm² ... 2.5 mm²
Main circuit OUT
Connection method Push-in connection
Stripping length 10 mm
Conductor cross section solid 0.2 mm² ... 2.5 mm²
AWG conductor cross section 24 ... 12
Conductor cross section flexible, with ferrule, with plastic
sleeve
0.25 mm² ... 1.5 mm²
Conductor cross section flexible, with ferrule, w/o plastic
sleeve
0.25 mm² ... 2.5 mm²
