Phonic DMX1501 User Manual

14
DMX1501/2501
SPECIFICATION
DMX 1501
260 W
400 W
290 W
470 W
720 W
810 W
940 W
1430 W
< 0.01 %
31 dB
DMX 2501
450 W
650 W
500 W
760 W
1200 W
1300 W
1530 W
2400 W
< 0.02 %
34 dB
Model Name
Power/Channel, Both channel driven
8Ω, 20 Hz-20 kHz, 0.1% THD
4Ω, 20 Hz-20 kHz, 0.1% THD
8Ω,1 kHz (EIA), 0.1% THD
4Ω,1 kHz (EIA), 0.1% THD
2Ω,1 kHz (EIA), 0.1% THD
Power/Bridge Mono
8Ω, 20 Hz-20 kHz, 0.1% THD
8Ω,1 kHz (EIA), 0.1% THD
4Ω,1 kHz (EIA), 0.1% THD
Performance
Frequency Response 20 Hz – 20 kHz (+0/-1dB)
5 Hz – 60 kHz, (-3dB drop point)
Damping Factor > 300 @ 8Ω
Total Harmonic Distortion
Input Sensitivity @ 8 Ohm 1.23Vrms / 4.0dBu
Gain
Signal/Noise 100 dB, 20 Hz – 20 kHz.
Low Frequency Filter 30 or 50Hz, selectable
Controls & Indicators
Front Panel Power Switch, Gain Controls
Rear Panel Mode
(Stereo, Parallel, Bridge, LF lter, Limiter), via 10-position DIP switch.
Power Blue LED
Signal Green LED, 1 per channel
Peak Red LED, 1 per channel
Connectors (each channel)
Input Balanced XLR and 1/4” TRS
Output SPEAKON connector & Binding Post
Protection
Cooling system Fan Cooled, speed regulated, thermal protection.
Amplier Protection against short circuit, no-load and RF interference conditions.
Stable into reactive or mismatch loads.
Loudspeaker/Load Turn-ON/Off Muting, AC coupling
Weight 16 kg (35.2 lbs) 17 kg (37.4 lbs)

Phonic DMX1501 Specifications

General

Brand	Phonic
Model	DMX1501
Category	Amplifier
Language	English
