Phonic XP 5000 User Manual

6 XP 600/1000/2000/2100/3000/3100/5000/5100
English
SPECIFICATIONS
XP 600 XP 1000 XP 2000 / XP 2100 XP 3000 / XP 3100
Stereo Mode (driving both channels) Continuous Average Output Power Per Channel
8Ω 20Hz-20KHz 0.03% THD 125W 250W 400W 600W
4Ω 20Hz-20KHz 0.05% THD 200W 400W 600W 1000W
8Ω EIA 1KHz 1% THD 140W 275W 450W 650W
4Ω EIA 1KHz 1% THD 220W 440W 660W 1100W
2Ω EIA 1KHz 1% THD 280W 560W 960W 1400W
Bridge Mono Mode Continuous average Output Power
8Ω 20Hz-20KHz 0.1% THD 400W 800W 1200W 2000W
4Ω 1KHz 1% THD 560W 1120W 1920W 2800W
All Models
Input sensitivity @ 8 1 Vrms 1.4 Vrms 1.73 Vrms
Input sensitivity @ 4 Ω 0.9 Vrms 1.25 Vrms 1.23 Vrms 1.58 Vrms
Noise (unweighted 20Hz-20KHz below rated
output)
106 dB 107 dB
Distortion (SMPTE-IM) <0.01% <0.02%
Damping Factor >200 @ 8Ω >500 @ 8Ω
Output Circuitry Class H Amplier
Filtering High pass lter (30Hz, 50Hz)
Subwoofer output
Selectable subwoofer crossover at 60Hz, 90Hz, 120Hz for subwoofer
output (XP 2100, XP 3100 only)
Frequency Response 20Hz-20KHz, 0/-1dB, -3dB points: 5Hz-100KHz
Input Impedance 20 kΩ balanced, 10 kΩ unbalanced
Cooling Dual continuous variable-speed fans, front-to-rear air ow
Connectors (each channel) Input: XLR & 1/4” TRS jacks Output: Speakon & binding posts
Indicators
Power: Amber Phonic logo; Parallel: Green backlight icon;
Bridged: Red backlight icon; CLIP/LIM: Red LED;
PROTECT: Yellow LED Green LED for -10dB, -20dB and -40dB Signal Lights
Front panel controls
CH1 & CH2 GAIN knobs with 41 detents; selectable low frequency crossover at 60Hz,
90Hz and 120Hz (XP 2100 and XP 3100 only)
Amplier Protection
Short circuit, thermal, subsonic, RF protection, Output DC offset, Heatsink and
transformer over-heat protection, Power on/off muting, Soft start power on
Gain 32x (30dB) 40x (32dB)
Power Consumption 150W 293W 880W 1460W
Dimensions (WxHxD) 482 x 105 x 400mm (19" x 4" x 15.7") 482 x 150 x 400mm (19" x 5.9" x 15.7")
Weight 15kg (33lbs) 16.6kg (36.7lbs) 20.68kg (45.6lbs) 24.2kg (53.3lbs)
6

Phonic XP 5000 Specifications

General

Power Output (4 Ohms Bridged)	3200W
Signal to Noise Ratio	> 100dB
Cooling	Variable speed fan
Input Impedance	20 kΩ Balanced, 10 kΩ Unbalanced
Connectors (Input)	XLR and 1/4" TRS
Channels	2
Damping Factor	> 300
Total Harmonic Distortion	<0.03%
Input Sensitivity	1.4V
Dimensions	483 x 451 x 88 mm
Connectors (Output)	Speakon and Binding Post
Protection	Thermal, short circuit, DC, overload
Frequency Response	20Hz - 20kHz (±0.5dB)
