PI N470 Series User Manual

10 Technical Data
N-470 Linear Actuator MP125E Version: 1.2.0 41
Models that are not suitable for use in a vacuum
Number of steps
per second*
Operating time Duty cycle (max.) / idle time
2000
60 s (max.)
20 % / 4 min
2000 10 s 20 % / 40 s
1000 120 s (max.) 40 % / 180 s
1000 10 s 40 % / 15 s
≤400
unlimited
unlimited
* To be set via the Maximum Motor Output operating parameter (0x9) for the E-872.401
respectively PIShift Steps per Second for the E-870.
The following graph shows the operating time in seconds depending on the number of steps
per second.
Figure 13: Operating time in s vs. steps/s
