Parameter ID
(hexa-
decimal)
Command
Level
for write
access
Item Type
Concerned
Data
Type
Parameter
Description
Notes
0x07001500 1 PiezoWalk
Channel
FLOAT PiezoWalk Forward
Correction 1
Coefficients of step forward linearization
polynomial of piezo-voltage-to-position-
calculation.
Coefficients are used to compensate for
the piezo nonlinearity.
If 0x07001500 is set to 1 and all other
coefficients are set to 0, linearization is
disabled.
0x07001501 1 PiezoWalk
Channel
FLOAT PiezoWalk Forward
Correction 2
0x07001502 1 PiezoWalk
Channel
FLOAT PiezoWalk Forward
Correction 3
0x07001503 1 PiezoWalk
Channel
FLOAT PiezoWalk Forward
Correction 4
0x07001504 1 PiezoWalk
Channel
FLOAT PiezoWalk Forward
Correction 5
0x07001505 1 PiezoWalk
Channel
FLOAT PiezoWalk Forward
Correction 6
0x07001600 1 PiezoWalk
Channel
FLOAT PiezoWalk Backward
Correction 1
Coefficients of step backward
linearization polynomial of piezo-voltage-
to position-calculation.
Coefficients are used to compensate for
the piezo nonlinearity.
If 0x07001600 is set to 1 and all other
coefficients are set to 0, linearization is
disabled.
0x07001601 1 PiezoWalk
Channel
FLOAT PiezoWalk Backward
Correction 2
0x07001602 1 PiezoWalk
Channel
FLOAT PiezoWalk Backward
Correction 3
0x07001603 1 PiezoWalk
Channel
FLOAT PiezoWalk Backward
Correction 4
0x07001604 1 PiezoWalk
Channel
FLOAT PiezoWalk Backward
Correction 5
0x07001605 1 PiezoWalk
Channel
FLOAT PiezoWalk Backward
Correction 6
