Parameter ID
(hexa-
decimal)
Command
Level
for write
access
Item Type
Concerned
Data
Type
Parameter
Description
Notes
0x07001900 1 PiezoWalk
Channel
FLOAT PiezoWalk Clamp-Free
Voltage
Used for nanostepping mode only.
When the amounts of the two clamping
voltages exceed the value of the clamp-
free voltage parameter, the piezo
actuator pair provided with the negative
clamping voltage is lifted off the runner
while the pair provided with the positive
clamping voltage clamps the runner.
When a piezo actuator pair is lifted, its
shearing component moves back to the
starting position. The clamp-free
parameter affects the duration of that
phase: the lower the clamp-free voltage
value, the longer that phase and the
shorter the phase where the piezo
actuator pair is in contact with the
runner, causing the feed.
0x07001a00 1 PiezoWalk
Channel
INT PiezoWalk Driving
Mode
Selects the driving mode:
0 = Full-step mode
1 = Nanostepping mode
2 = Analog mode (if selected, no stepping
motion is possible)
0x07011700 1 PiezoWalk
Channel
FLOAT PiezoWalk Step Size [µm]
The feed caused by one step cycle, with
maximum amplitude of the shearing
voltages
(V
Dmax
– V
Dmin
).
Can be determined as follows: Perform n
steps using OSM, measure the position
difference and divide it by the number of
steps.
