STEERING
Specification Desc./Quantity
Steering Built with tube pivoted on the arm with front wheel-holder os-
cillating hub.
SUSPENSION
Specification Desc./Quantity
Front suspension Built using helical spring.
Rear suspension Built with flexible rubber components in progressive rate. Sus-
pensions consist of hydraulic shock absorbers.
TYRES
Specification Desc./Quantity
Wheel rim From 3.50".
Front wheel and spare wheel "Normal" type 4.00-12 C- PR6.
Rear wheels "Radial" type 4.00-12 C- PR6. (for example Michelin C-XZX
PR.6. for deck, van, tipper, Urban Cleansing van and cabriolet
versions).
"Radial" type 4.00-R12 C- PR8. (for example Michelin C-XZX
PR.8. for versions with external fixed elaborations and those
with hydraulic tipping).
Front tyre pressure 2.8 bar
Rear tyres - inflation pressure 4.5 bar
N.B.:
When installing the spare wheel in place of one of the rear wheels (for example due to a puncture) it is recommended to replace
it as soon as possible by reinstalling the "radial" tyre which is more suitable for use.
It is not advisable to install the radial tyre on the front wheel as there would be excessive sensitivity, especially when driving on
twisting or bumpy roads.
REFILLING
(*)= specific for versions with tipper deck.
Litres (l)
Deck Long
Deck
Van Tipper
Fuel tank (reserve) 15 (3.5) 15 (3.5) 15 (3.5) 15 (3.5)
Engine oil (reserve) 3.0 (0.75) 3.0 (0.75) 3.0 (0.75) 3.0 (0.75)
Hydraulic oil (*) 3.0 3.0 3.0 3.0
DIMENSIONS - APE TM KAT - APE TM P703 FL2
millimetres
Deck Long
Deck
Van Tipper Motor
chassis
(1) Length 3175 3390 3210 3225 3150
(2) Width 1480 - - 1500
(3) Height 1630 1630 1780 1630
(4) Wheelbase 2170 2170 2170 2170
(5) Track 1300 1300 1300 1300
(6) Turning spokes 3300 3300 3300 3300
WEIGHTS - APE TM KAT - APE TM P703 FL2
(*) = without the driver
(*) = including the driver
Kilograms (kg)
Deck Long
Deck
Van Tipper
Dry weight (*) 465 465 505 505
Vehicle weight in running order (with refuelling, tools and accessories) 1270 1270 1270 1270
Load capacity (**) 805 805 765 765
Characteristics APE TM Benzina
CH - 16
