TECHNICAL DATA - CHASSIS - APE TM KAT - APE TM P703 FL2
Specification Desc./Quantity
Chassis Sheet steel body and a single central longitudinal arm (inte-
grated structure).
Versions Sheet metal deck, integrated into the structure.
Long deck.
Aluminium alloy deck, hydraulic tipper for engine inspection.
Driver's cab Welded to the chassis.
Seats in driving cab Two.
TECHNICAL DATA - ENGINE - APE TM KAT
Specification Desc./Quantity
Matriculation data The identification codes consist of a prefix (ATM2T on the
chassis, ATM2M on the engine) and a number.
Engine Single-cylinder, 2-stroke engine, with "rotating" timing and with
three transfer ducts, with transmission and differential grouped
on the axis of the rear wheels.
Engine capacity 217.9 cm³
Bore X Stroke 68 x 60
Compression ratio 8.6 : 1
Ignition advance 14° ± 1°30' before T.D.C.:
Carburettor Dell'Orto SHB 22/22.
Fuel Pure petrol with separate engine lubrication, "LS" device.
Spark plug Champion RL78C; NGK BR8HS.
Maximum speed (CUNA STANDARDS) 60÷65 km/h.
Air filter At the intake of the type with paper cartridge filter.
Consumption (CUNA) ~4.1 litres per 100 km.
Km range Around 330 Km.
TECHNICAL DATA - ENGINE - APE TM P703 FL2
Specification
Desc./Quantity
Matriculation data The identification codes consist of a prefix (ATM2T on the
chassis, ATM2M on the engine) and a number.
Engine Single-cylinder, 2-stroke engine, with "rotating" timing and with
three transfer ducts, with transmission and differential grouped
on the axis of the rear wheels.
Engine capacity 217.9 cm³
Bore X Stroke 68 x 60
Compression ratio 8.6 : 1
Ignition advance 14° ± 1°30' before T.D.C.:
Carburettor Dell'Orto SHB 22/22.
Fuel Pure petrol with separate engine lubrication, "LS" device.
Spark plug Bosch W4AC; Lodge 3HN; Champion L78C AC430Z.
Maximum speed (CUNA STANDARDS) 60÷65 km/h.
Air filter At the intake of the type with paper cartridge filter.
Consumption (CUNA) ~4.1 litres per 100 km.
Km range Around 330 Km.
TRANSMISSION - APE TM KAT - APE TM P703 FL2
Specification
Desc./Quantity
Gear ratio First 1/48.47
Gear ratio Second 1/26.54
Gear ratio Third 1/15.56
Gear ratio Fourth 1/9.16
Gear ratio Reverse 1/80.78
STEERING - APE TM KAT - APE TM P703 FL2
Specification
Desc./Quantity
Steering Built with tube pivoted on the arm with front wheel-holder os-
cillating hub.
APE TM Benzina Characteristics
CH - 17
