20. Start-up relay.
21. Main fuse (25A).
22. Voltage regulator.
23. Magneto flywheel.
24. Dynamotor.
25. Spark plug.
26. Electronic control unit.
27. Oil warning light control.
28. Rear light with twin-filament daylight running light/stop bulb (12V-5W/21W), reverse bulb (12V-21W
for rear right light), rear fog light bulb (12V-21W for left rear light), turn indicator bulb (12V-21W).
29. License plate light (12V-5W bulb).
30. Load box tilting device warning light (12V-3W).
31. Load box tilting button.
32. Van lighting fuse (8A).
33. Van lighting bulb (12V-5W).
34. Van lighting switch.
35. Headlight switch and horn button.
COLOUR CODE:
Ar: Orange
Az: Blue
Bi: White
Gi: Yellow
Gr: Grey
Ne: Black
Ro: Pink
Rs: Red
Ve: Green
Vi: Purple
Electrical System Diagram (version with steering wheel)
APE TM Benzina Electrical system
ES - 51
