Location: Helmet compartment
Fuse No. 3 Position on fuse holder: 3
Capacity: 10 A
Protected circuits: High- and low-
beam lights - Front and rear tail
lights - License plate bulb
Location:helmet compartment
Fuse No. 4 Position on fuse holder: 4
Capacity: 7.5 A
Protected circuits: Power for
radio/intercom control unit pre-
installation - Analogue indicator
Location:helmet compartment
Fuse No. 5 Position on fuse holder: 5
Capacity: 7.5 A
Protected circuits: Headlight
warning light - Front and rear tail
lights - License plate light
Location: front case
Fuse No. 6 Position on fuse holder: 6
Capacity: 10 A
Protected circuits: Digital
instrument panel - Immobilizer
LED
Location: front case
59
