11
Landing Gear Assembly
2. Install the landing gear axles with
lock nut.
4. Install wheels and wheel collars
using Blue Loctite on the set screws.
3. Tighten the lock nut against the
landing gear strut making sure the flat
sides of the axle bolt vertical with
ground.
1. Install the landing gear with the
bolts and locking nuts. Do not over
tighten the hardware.
