25
4. Apply 30 minutes epoxy inside the
pre-cut slot for horn, and coat the
horn with epoxy as shown.
Servo Installation
Elevator Servo Assembly
1. Connect the servo extension to
the servo and install safety clip.
5. Slide the horn with locking plate
into place. Wipe away excess
epoxy with rubbing alcohol.
To Next Page
