Ignition Module
Ignition Module
1. Attach foam rubber to the bottom
of ignition with double sided tape and
install spiral wrap cover to ignition
lead as shown.
2. Stick the ignition to the outside of
the engine box with double sided tape.
Allow room for spark plug leads and
wire connections. Drill holes in motor
box for zip ties and secure module
with ties.
3. The ignition battery installs the
same manor except under the engine
box. Lock the connectors with the
provided safety clip to prevent
vibration from loosening connections.
