23
Elevator Servo Assembly
Minimum servo specs:
1. Turn on your transmitter and
make sure servos are centered
before putting on servo arms.
2. Ensure the servo arm is 90
degrees with servo as shown. Then
mark and drill holes with 2mm bit.
3. Mount the screws and nuts.
180 in. oz / Metal Gear / Digital
Use a drop of CA
glue on each nut.
Servo Arm Installation
Use a few drops of CA
to hold arm in place for
drilling.
