Pilz P2HZ X1 User Manual

P2HZ X1
Operating Manual P2HZ X1
20124-EN-09
| 16
Electrical data 774330 774332 774340
Two-hand control relay
type
in accordance with the
standard EN ISO 13851 EN ISO 13851 EN ISO 13851
Type III C III C III C
Inputs 774330 774332 774340
Quantity 2 2 2
Voltage at
Input circuit DC 24 V 24 V 24 V
Feedback loop DC 24 V 24 V 24 V
Current at
Feedback loop DC 45 mA 45 mA 45 mA
Semiconductor outputs 774330 774332 774340
Quantity 2 2 2
Voltage 24 V 24 V 24 V
Current 20 mA 20 mA 20 mA
External supply voltage 24 V 24 V 24 V
Voltage tolerance -15 %/+10 % -15 %/+10 % -15 %/+10 %
Residual current at "0"
signal 0,1 mA 0,1 mA 0,1 mA
Max. internal voltage drop 4 V 4 V 4 V
Conditional rated short cir-
cuit current 100 A 100 A 100 A
Lowest operating current 0 mA 0 mA 0 mA
Utilisation category in ac-
cordance with EN
60947-1 DC-12 DC-12 DC-12
Relay outputs 774330 774332 774340
Number of output con-
tacts
Safety contacts (N/O),
instantaneous 3 3 3
Auxiliary contacts (N/C) 1 1 1
Max. short circuit current
IK 1 kA 1 kA 1 kA
Utilisation category
in accordance with the
standard EN 60947-4-1 EN 60947-4-1 EN 60947-4-1

Pilz P2HZ X1 Specifications

General

Brand	Pilz
Model	P2HZ X1
Category	Relays
Language	English
