Pilz P2HZ X1 User Manual

P2HZ X1
Operating Manual P2HZ X1
20124-EN-09
| 18
Relay outputs 774330 774332 774340
External contact fuse pro-
tection, safety contacts
in accordance with the
standard EN 60947-5-1 EN 60947-5-1 EN 60947-5-1
Max. melting integral 240 A²s 240 A²s 240 A²s
Blow-out fuse, quick 6 A 6 A 6 A
Blow-out fuse, slow 4 A 4 A 4 A
Blow-out fuse, gG 6 A 6 A 6 A
Circuit breaker 24V
AC/DC, characteristic
B/C 4 A 4 A 4 A
External contact fuse pro-
tection, auxiliary contacts
Max. melting integral 240 A²s 240 A²s 240 A²s
Blow-out fuse, quick 4 A 4 A 4 A
Blow-out fuse, slow 2 A 2 A 2 A
Blow-out fuse, gG 4 A 4 A 4 A
Circuit breaker, 24
VAC/DC, character-
istic B/C 2 A 2 A 2 A
Conventional thermal cur-
rent 5 A 5 A 5 A
Contact material AgSnO2 + 0,2 µm Au AgSnO2 + 0,2 µm Au AgSnO2 + 0,2 µm Au
Times 774330 774332 774340
Delay-on de-energisation
(response time tA in ac-
cordance with EN ISO
13851)
N/O contact 15 ms 15 ms 15 ms
N/C contact 30 ms 30 ms 30 ms
Recovery time 250 ms 250 ms 250 ms
Simultaneity, channel 1
and 2 max. 500 ms 500 ms 500 ms
Environmental data 774330 774332 774340
Climatic suitability EN 60068-2-78 EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -25 - 55 °C -25 - 55 °C -25 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during op-
eration Not permitted Not permitted Not permitted
EMC EN 60947-5-1, EN
61000-6-2
EN 60947-5-1, EN
61000-6-2
EN 60947-5-1, EN
61000-6-2
