Technical details
Operating Manual PDP67 F 4 code
1001531-EN-06
22
9 Technical details
General 773603 773613
Approvals CE, cULus Listed CE, cULus Listed
Electrical data 773603 773613
Supply voltage
Voltage 24 V 24 V
Kind DC DC
Current load capacity at UB 2 A 2 A
Environmental data 773603 773613
Climatic suitability EN 60068-2-1, EN 60068-2-14, EN
60068-2-2
EN 60068-2-1, EN 60068-2-14, EN
60068-2-2
Ambient temperature
In accordance with the standard EN 60068-2-14 EN 60068-2-14
Temperature range -40 - 60 °C -40 - 60 °C
Storage temperature
In accordance with the standard EN 60068-2-1/-2 EN 60068-2-1/-2
Temperature range -40 - 70 °C -40 - 70 °C
Climatic suitability
In accordance with the standard EN 60068-2-78 EN 60068-2-78
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during operation Short-term Short-term
Vibration
In accordance with the standard EN 60068-2-6 EN 60068-2-6
Frequency 10 - 55 Hz 10 - 55 Hz
Amplitude 0,35 mm 0,35 mm
Shock stress
In accordance with the standard EN 60068-2-27 EN 60068-2-27
Number of shocks 3 3
Duration 11 ms 11 ms
In accordance with the standard EN 60068-2-27 EN 60068-2-27
Number of shocks 500 500
Duration 16 ms 16 ms
Airgap creepage
In accordance with the standard EN 60664-1 EN 60664-1
Overvoltage category II II
Pollution degree 2 2
Protection type
Housing IP67 IP67
Terminals IP67 IP67
Mechanical data 773603 773613
Material
Top PBT PBT
Connection type M12 Stainless steel 1.4305
Mounting type screw interlocked screw interlocked
