Inputs 774133 784133
Max. overall cable resistance Rl-
max
Start circuit and feedback loop 1.000 Ohm 1.000 Ohm
Input circuit, single-channel 1.000 Ohm 1.000 Ohm
Input circuit, dual-channel 2.000 Ohm 2.000 Ohm
Max. line capacitance 450 nF 450 nF
Semiconductor outputs 774133 784133
Overall performance ext. loading,
semiconductor 130 W 130 W
Number of safety outputs
Instantaneous 2 2
Number of auxiliary outputs 1 1
Number of test pulse outputs 2 2
Switching capability, 2 safety out-
puts under load
Current at UB ≤ 26.5 V 2 A 2 A
Current at UB > 26,5 V 1,5 A 1,5 A
Power at UB ≤ 26.5 V 50 W 50 W
Power at UB > 26,5 V 45 W 45 W
Switching capability, 1 safety out-
put under load
Current at UB ≤ 26.5 V 2,7 A 2,7 A
Current at UB > 26,5 V 2,2 A 2,2 A
Power at UB ≤ 26.5 V 70 W 70 W
Power at UB > 26,5 V 65 W 65 W
Max. line capacitance at the out-
puts without load 2 nF 2 nF
Voltage auxiliary and test pulse
outputs 24 V 24 V
Current auxiliary and test pulse
outputs 0,5 A 0,5 A
Times 774133 784133
Switch-on delay
After power on 3 s 3 s
With automatic start typ. 100 ms 100 ms
With automatic start max. 180 ms 180 ms
With monitored start typ. 180 ms 180 ms
With monitored start max. 260 ms 260 ms
Logic inputs typ. 120 ms 120 ms
Logic inputs max. 200 ms 200 ms
Response time tr semiconductor
outputs
typ. 40 ms 40 ms
max. 43 ms 43 ms
Maximum time of feedback loop
monitoring 150 ms 150 ms
