PNOZ e1.1p
Operating Manual PNOZ e1.1p
21238-EN-06
30
Mechanical data 774133 784133
Torque setting with screw terminals 0,5 Nm –
Conductor cross section with
spring-loaded terminals: Flexible
with/without crimp connector – 0,2 - 1,5 mm², 24 - 16 AWG
Spring-loaded terminals: Terminal
points per connection – 2
Stripping length with spring-loaded
terminals – 8 mm
Dimensions
Height 94 mm 101 mm
Width 22,5 mm 22,5 mm
Depth 121 mm 121 mm
Weight 130 g 130 g
Where standards are undated, the 2014-07 latest editions shall apply.
Safety characteristic data
NOTICE
You must comply with the safety-related characteristic data in order to
achieve the required safety level for your plant/machine.
Operating
mode
EN ISO
13849-1:
2015
PL
EN ISO
13849-1:
2015
Category
EN 62061
SIL CL
EN 62061
PFH
D
[1/h]
IEC 61511
SIL
IEC 61511
PFD
EN ISO
13849-1:
2015
T
M
[year]
SC output
via logic in-
put PL e Cat. 4 SIL CL 3 3,61E-09 SIL 3 5,82E-05 20
SC output
via 2-ch. in-
put circuit PL e Cat. 4 SIL CL 3 3,44E-09 SIL 3 4,53E-05 20
All the units used within a safety function must be considered when calculating the safety
characteristic data.
INFORMATION
A safety function's SIL/PL values are not identical to the SIL/PL values of
the units that are used and may be different. We recommend that you use
the PAScal software tool to calculate the safety function's SIL/PL values.
