PNOZ e1.1p
Operating Manual PNOZ e1.1p
21238-EN-06
31
Remove plug-in terminals
Procedure: Insert the screwdriver into the housing recess behind the terminal and lever the
terminal out.
Do not remove the terminals by pulling the cables!
Order reference
Product
Product type Features Connection type Order no.
PNOZ e1.1p 24 VDC Screw terminals 774 133
PNOZ e1.1p C 24 VDC Spring-loaded terminal 784 133
Accessories
Product type Features Order no.
Terminal block filter 1 Terminal block with filter for 3-10 kOhm load range 774 195
Terminal block filter 2 Terminal block with filter for 10-30 kOhm load range 774 196
