Operation
Operating Manual PNOZ m B0
1002660-EN-02
26
Pull out and retract the knob




The rotary knob:
} (A) should be pulled out until it clicks into position
} (B) then released and retracted back into the unit:
– Press the latch on the side of the rotary knob (1) towards the centre of the knob.
This releases the rotary knob.
– Press the knob downwards (2) while keeping the latch held down.
Rotate and press the knob
The settings are made via the rotary knob, as follows:
Press the knob
} Confirm selection/setting
} Switch to menu
Rotate knob
} Select menu level
7.2.1.2
7.2.1.3
