Technical details
Operating Manual PNOZ m B0
1002660-EN-02
30
Technical details
General 772100
Approvals BG, CCC, CE, GOST, TÜV
Application area Failsafe
Module's device code 0060h
Electrical data 772100
Supply voltage
for Supply to the system
Voltage 24 V
Type DC
Voltage tolerance -20 %/+25 %
Max. continuous current that the external power
supply must provide
1,6 A
Inrush current that the external power supply must
provide
3,0 A
Supply voltage
for Supply to the SC outputs
Voltage 24 V
Type DC
Voltage tolerance -20 %/+25 %
Max. continuous current that the external power
supply must provide
8,0 A
Potential isolation Yes
Supply voltage
Module's current consumption 32 mA
Module's power consumption 0,8 W
Max. power dissipation of module 7,40 W
Status indicator Display, LED
Permitted loads Inductive, capacitive, resistive
Configurable inputs/outputs (inputs or auxiliary
outputs)
772100
Number 8
Potential isolation nein
Configurable inputs
Input voltage in accordance with EN 61131-2 Type
1
24,0 V
Input current at rated voltage 5 mA
Input current range 2,5 - 5,3 mA
Pulse suppression 0,5 ms
Maximum input delay 2,0 ms
Configurable auxiliary outputs
Voltage 24,0 V
Output current 75 mA
Output current range 0 - 100 mA
Max. transient pulsed current 500 mA
Short circuit-proof Yes
Residual current at "0" 0,5 mA
