Technical details
Operating Manual PNOZ m B0
1002660-EN-02
31
Configurable inputs/outputs (inputs or auxiliary
outputs)
772100
Voltage at "1" UB - 2 V at 0.1 A
Inputs 772100
Number 12
Voltage at inputs 24 V DC
Input current at rated voltage 5 mA
Input current range 2,5 - 5,3 mA
Pulse suppression 0,5 ms
Maximum input delay 2 ms
Potential isolation No
Test pulse outputs 772100
Number of test pulse outputs 4
Voltage 24 V
Current 0,1 A
Max. duration of off time during self test 5 ms
Short circuit-proof Yes
Potential isolation No
Semiconductor outputs 772100
Number of positive-switching single-pole semicon-
ductor outputs
4
Switching capability
Voltage 24 V
Current 2,0 A
Permitted current range 0,00 - 2,50 A
Residual current at "0" signal 0,05 mA
Max. transient pulsed current 12 A
Max. capacitive load 1 µF
Max. internal voltage drop 500 mV
Max. duration of off time during self test 330 µs
Switch-off delay 1 ms
Potential isolation Yes
Short circuit-proof Yes
Times 772100
Simultaneity in the two-hand circuit 0,5 s
Processing time 30 ms
Environmental data 772100
Ambient temperature
In accordance with the standard EN 60068-2-14
Temperature range 0 - 60 °C
Forced convection in control cabinet off 55 °C
Storage temperature
In accordance with the standard EN 60068-2-1/-2
Temperature range -25 - 70 °C
Climatic suitability
In accordance with the standard EN 60068-2-30, EN 60068-2-78
Condensation Not permitted
