Technical details
Operating Manual PNOZ m B0
1002660-EN-02
32
Environmental data 772100
EMC EN 61131-2
Vibration
In accordance with the standard EN 60068-2-6
Frequency 5,0 - 150,0 Hz
Max. acceleration 1g
Airgap creepage
In accordance with the standard EN 61131-2
Overvoltage category II
Pollution degree 2
Rated insulation voltage 30 V
Shock stress
In accordance with the standard EN 60068-2-27
Acceleration 15g
Duration 11 ms
Max. operating height above sea level 2000 m
Potential isolation 772100
Potential isolation between SC output and system voltage
Type of potential isolation Basic insulation
Rated surge voltage 2500 V
Mechanical data 772100
Mounting position Horizontal on top hat rail
Protection type
In accordance with the standard EN 60529
Mounting (e.g. cabinet) IP54
Housing IP20
Terminals IP20
DIN rail
Top hat rail 35 x 7,5 EN 50022
Recess width 27 mm
Max. cable length
Max. cable length per input 1,0 km
Sum of individual cable lengths at the test pulse
output
2 km
Material
Bottom PC
Front PC
Top PC
Cross section of external conductors with screw
terminals
1 core flexible 0,25 - 2,50 mm², 24 - 12 AWG
2 core with the same cross section, flexible without
crimp connectors or with TWIN crimp connectors
0,20 - 1,50 mm², 24 - 16 AWG
Torque setting with screw terminals 0,50 Nm
Connection type Spring-loaded terminal, screw terminal
Mounting type plug in
Cross section of external conductors with spring-load-
ed terminals: flexible with/without crimp connector
0,20 - 2,50 mm², 24 - 12 AWG
