Overview
Operating Manual PNOZ m B0
1002660-EN-02
9
Front view
Front view with and without cover
Key
} X1:
– Inputs I8 ... I15
} X2:
– Configurable test pulse/auxiliary outputs T0M20 ... T3M23
– Semiconductor outputs O0 ... O3
} X3:
– Configurable inputs/outputs IM0 – IM3
– Inputs I4 ... I7
} X4:
– Configurable inputs/outputs IM16 – IM19
– Supply connections
} LEDs:
– POWER
– RUN
– DIAG
– FAULT
– I FAULT
– O FAULT
2.4
