PNOZ s3
Operating Manual PNOZ s3
21395-EN-12
18
Technical Details
General 750103 751103
Approvals
CCC, CE, EAC (Eurasian),
KOSHA, TÜV, cULus Listed
CCC, CE, EAC (Eurasian),
KOSHA, TÜV, cULus Listed
Electrical data 750103 751103
Supply voltage
Voltage 24 V 24 V
Kind DC DC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(DC) 2,5 W 2,5 W
Residual ripple DC 20 % 20 %
Duty cycle 100 % 100 %
Max. inrush current impulse
Current pulse, A1 0,5 A 0,5 A
Pulse duration, A1 5 ms 5 ms
Inputs 750103 751103
Number 2 2
Voltage at
Input circuit DC 24 V 24 V
Start circuit DC 24 V 24 V
Feedback loop DC 24 V 24 V
Current at
Input circuit DC 50 mA 50 mA
Start circuit DC 50 mA 50 mA
Feedback loop DC 50 mA 50 mA
Max. inrush current impulse
Current pulse, input circuit 0,2 A 0,2 A
Pulse duration, input circuit 100 ms 100 ms
Current pulse, feedback loop 0,2 A 0,2 A
Pulse duration, feedback loop 15 ms 15 ms
Current pulse, start circuit 0,2 A 0,2 A
Pulse duration, start circuit 15 ms 15 ms
Min. input resistance at power-on 110 Ohm 110 Ohm
Max. overall cable resistance Rl-
max
Single-channel at UB DC 30 Ohm 30 Ohm
Dual-channel without detection
of shorts across contacts at UB
DC 60 Ohm 60 Ohm
Dual-channel with detection of
shorts across contacts at UB DC 30 Ohm 30 Ohm
Semiconductor outputs 750103 751103
Number 1 1
Voltage 24 V 24 V
