Operating Manual PNOZ s3
21395-EN-12
20
Times 750103 751103
Switch-on delay
With automatic start typ. 170 ms 170 ms
With automatic start max. 300 ms 300 ms
With automatic start after power
on typ. 350 ms 350 ms
With automatic start after power
on max. 600 ms 600 ms
With manual start typ. 40 ms 40 ms
With monitored start with rising
edge typ. 35 ms 35 ms
With monitored start with rising
edge max. 50 ms 50 ms
With monitored start with falling
edge typ. 55 ms 55 ms
With monitored start with falling
edge max. 70 ms 70 ms
Delay-on de-energisation
With E-STOP typ. 10 ms 10 ms
With E-STOP max. 20 ms 20 ms
With power failure typ. 40 ms 40 ms
With power failure max. 60 ms 60 ms
Recovery time at max. switching
frequency 1/s
After E-STOP 100 ms 100 ms
After power failure 100 ms 100 ms
Waiting period with a monitored
start
With rising edge 120 ms 120 ms
With falling edge 250 ms 250 ms
Min. start pulse duration with a
monitored start
With rising edge 30 ms 30 ms
With falling edge 100 ms 100 ms
Supply interruption before de-ener-
gisation 20 ms 20 ms
Simultaneity, channel 1 and 2 max. ∞ ∞
Environmental data 750103 751103
Climatic suitability EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during operation Not permitted Not permitted
EMC EN 60947-5-1, EN 61000-6-2, EN
61000-6-4, EN 61326-3-1
EN 60947-5-1, EN 61000-6-2, EN
61000-6-4, EN 61326-3-1

Pilz PNOZ s3 Specifications

General

Product Type	Safety Relay
Safety Integrity Level	SIL CL 3
Supply Voltage	24 V DC
Number of Auxiliary Contacts	1
Width	22.5 mm
Rated Operational Current Ie	6 A
Protection Class	IP20
Stop Category	0
Standards	EN ISO 13849-1, IEC 62061, EN 60947-5-1, EN 60204-1
Weight	150 g
Number of Safety Contacts	3
Ambient Temperature	-10 to 55 °C
