Operating Manual PNOZ s4.1
21890-EN-15
| 23
Technical details
General 750124 750154 751124 751154
Certifications
CCC, CE, EAC,
KOSHA, TÜV,
UKCA, cULus Lis-
ted
CCC, CE, EAC,
KOSHA, TÜV,
UKCA, cULus Lis-
ted
CCC, CE, EAC,
KOSHA, TÜV,
UKCA, cULus Lis-
ted
CCC, CE, EAC,
KOSHA, TÜV,
UKCA, cULus Lis-
ted
Electrical data 750124 750154 751124 751154
Supply voltage
Voltage 24 V 48 - 240 V 24 V 48 - 240 V
Kind DC AC/DC DC AC/DC
Voltage tolerance -15 %/+10 % -15 %/+10 % -15 %/+10 % -15 %/+10 %
Output of external
power supply
(AC) – 5 VA – 5 VA
Output of external
power supply
(DC) 2,5 W 2,5 W 2,5 W 2,5 W
Frequency range
AC – 50 - 60 Hz – 50 - 60 Hz
Residual ripple
DC 20 % 160 % 20 % 160 %
Duty cycle 100 % 100 % 100 % 100 %
Inputs 750124 750154 751124 751154
Quantity 2 2 2 2
Voltage at
Input circuit DC 24 V 24 V 24 V 24 V
Start circuit DC 24 V 24 V 24 V 24 V
Feedback loop
DC 24 V 24 V 24 V 24 V
Current at
Input circuit DC 50 mA 50 mA 50 mA 50 mA
Start circuit DC 50 mA 50 mA 50 mA 50 mA
Feedback loop
DC 50 mA 50 mA 50 mA 50 mA
Max. inrush current
impulse
Current pulse, in-
put circuit 0,2 A 0,2 A 0,2 A 0,2 A
Pulse duration, in-
put circuit 100 ms 100 ms 100 ms 100 ms
Current pulse,
feedback loop 0,2 A 0,2 A 0,2 A 0,2 A
Pulse duration,
feedback loop 15 ms 15 ms 15 ms 15 ms
Current pulse,
start circuit 0,2 A 0,2 A 0,2 A 0,2 A
Pulse duration,
start circuit 15 ms 15 ms 15 ms 15 ms
