Pilz PNOZ s4.1 User Manual

PNOZ s4.1
Operating Manual PNOZ s4.1
21890-EN-15
| 35
Remove plug-in terminals
Procedure
} Insert a suitable screwdriver into the housing recess behind the terminal.
Do not remove the terminals by pulling the cables!
} Lever the terminal out.
Order reference
Product type Features Connection type Order no.
PNOZ s4.1 24 V DC Screw terminals 750124
PNOZ s4.1 C 24 V DC Spring-loaded terminals 751124
PNOZ s4.1 48 - 240 VAC/DC Screw terminals 750154
PNOZ s4.1 C 48 - 240 VAC/DC Spring-loaded terminals 751154
EC declaration of conformity
This product/these products meet the requirements of the directive 2006/42/EC for ma-
chinery of the European Parliament and of the Council. The complete EC Declaration of
Conformity is available on the Internet at www.pilz.com/downloads.
Authorised representative: Norbert Fröhlich, Pilz GmbH & Co. KG, Felix-Wankel-Str. 2,
73760 Ostfildern, Germany
