Pilz PNOZ s4.1 User Manual

PNOZ s4.1
Operating Manual PNOZ s4.1
21890-EN-15
| 26
Relay outputs 750124 750154 751124 751154
Utilisation category
in accordance with
UL
Voltage
240 V AC G.U.
(same polarity)
240 V AC G.U.
(same polarity)
240 V AC G.U.
(same polarity)
240 V AC G.U.
(same polarity)
with current 1,5 A 1,5 A 1,5 A 1,5 A
Voltage 24 V DC G. U. 24 V DC G. U. 24 V DC G. U. 24 V DC G. U.
with current 4 A 4 A 4 A 4 A
External contact
fuse protection,
safety contacts
in accordance
with the standard EN 60947-5-1 EN 60947-5-1 EN 60947-5-1 EN 60947-5-1
Max. melting in-
tegral 66 A²s 66 A²s 66 A²s 66 A²s
Blow-out fuse,
quick 4 A 4 A 4 A 4 A
Blow-out fuse,
slow 3,15 A 3,15 A 3,15 A 3,15 A
Blow-out fuse, gG 4 A 4 A 4 A 4 A
Circuit breaker
24V AC/DC, char-
acteristic B/C 3 A 3 A 3 A 3 A
External contact
fuse protection, aux-
iliary contacts
Max. melting in-
tegral 66 A²s 66 A²s 66 A²s 66 A²s
Blow-out fuse,
quick 4 A 4 A 4 A 4 A
Blow-out fuse,
slow 3,15 A 3,15 A 3,15 A 3,15 A
Blow-out fuse, gG 4 A 4 A 4 A 4 A
Circuit breaker,
24 VAC/DC,
characteristic B/C 3 A 3 A 3 A 3 A
Conventional
thermal current 4 A 4 A 4 A 4 A
Contact material
AgCuNi + 0,2 µm
Au
AgCuNi + 0,2 µm
Au
AgCuNi + 0,2 µm
Au
AgCuNi + 0,2 µm
Au
