Pilz PNOZ X9P User Manual

PNOZ X9P
Operating Manual PNOZ X9P
1003362-EN-12
| 18
Technical details Order no. 777606, 787606
General 777606 787606
Certifications
CCC, CE, EAC (Eurasian), TÜV,
cULus Listed
CCC, CE, EAC (Eurasian), TÜV,
cULus Listed
Electrical data 777606 787606
Supply voltage
Voltage 24 - 240 V 24 - 240 V
Kind AC/DC AC/DC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(AC) 8,5 VA 8,5 VA
Output of external power supply
(DC) 5,5 W 5,5 W
Frequency range AC 50 - 60 Hz 50 - 60 Hz
Supply voltage
Voltage 24 V 24 V
Kind DC DC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(DC) 5,5 W 5,5 W
Residual ripple DC 160 % 160 %
Duty cycle 100 % 100 %
Inputs 777606 787606
Number 2 2
Voltage at
Input circuit DC 24 V 24 V
Start circuit DC 24 V 24 V
Feedback loop DC 24 V 24 V
Current at
Input circuit DC 50 mA 50 mA
Start circuit DC 100 mA 100 mA
Feedback loop DC 100 mA 100 mA
Min. input resistance at power-on 89 Ohm 89 Ohm
Max. overall cable resistance Rl-
max
Single-channel at UB DC 45 Ohm 45 Ohm
Single-channel at UB AC 45 Ohm 45 Ohm
Dual-channel without detection
of shorts across contacts at UB
DC 90 Ohm 90 Ohm
Dual-channel without detection
of shorts across contacts at UB
AC 90 Ohm 90 Ohm
Dual-channel with detection of
shorts across contacts at UB DC 15 Ohm 15 Ohm
Dual-channel with detection of
shorts across contacts at UB AC 15 Ohm 15 Ohm

Pilz PNOZ X9P Specifications

General

Brand	Pilz
Model	PNOZ X9P
Category	Relays
Language	English
