Pilz PNOZ X9P User Manual

PNOZ X9P
Operating Manual PNOZ X9P
1003362-EN-12
| 29
Mechanical data 777607 777609 787609
Conductor cross section
with screw terminals
1 core flexible
0,25 - 2,5 mm², 24 - 12
AWG
0,25 - 2,5 mm², 24 - 12
AWG –
2 core with the same
cross section, flexible
with crimp connectors,
no plastic sleeve
0,25 - 1 mm², 24 - 16
AWG
0,25 - 1 mm², 24 - 16
AWG –
2 core with the same
cross section, flexible
without crimp connect-
ors or with TWIN crimp
connectors
0,2 - 1,5 mm², 24 - 16
AWG
0,2 - 1,5 mm², 24 - 16
AWG –
Torque setting with screw
terminals 0,5 Nm 0,5 Nm –
Stripping length with
screw terminals 8 mm 8 mm –
Conductor cross section
with spring-loaded termin-
als: Flexible with/without
crimp connector – –
0,2 - 1,5 mm², 24 - 16
AWG
Spring-loaded terminals:
Terminal points per con-
nection – – 2
Stripping length with
spring-loaded terminals – – 8 mm
Dimensions
Height 94 mm 94 mm 101 mm
Width 90 mm 90 mm 90 mm
Depth 121 mm 121 mm 121 mm
Weight 570 g 570 g 570 g
Where standards are undated, the 2020-07 latest editions shall apply.
Safety characteristic data
NOTICE
You must comply with the safety characteristic data in order to achieve the
required safety level for your plant/machine.
Operating
mode
EN ISO
13849-1:
2015
PL
EN ISO
13849-1:
2015
Category
EN62061
SIL CL
EN62061
PFH
D
[1/h]
IEC 61511
SIL
IEC 61511
PFD
EN ISO
13849-1:
2015
T
M
[year]
– PL e Cat. 4 SIL CL 3 2,31E-09 SIL 3 2,03E-06 20
Explanatory notes for the safety-related characteristic data:
