Pilz PNOZ X9P User Manual

PNOZ X9P
Operating Manual PNOZ X9P
1003362-EN-12
| 27
Conventional thermal
current while loading
several contacts
777607 777609 787609
Ith per contact at UB DC;
AC1:240V,DC1:24V
Conv. therm. current
with 1 contact 8 A 8 A 8 A
Conv. therm. current
with 2 contacts 8 A 8 A 8 A
Conv. therm. current
with 3 contacts 8 A 8 A 8 A
Conv. therm. current
with 4 contacts 7 A 7 A 7 A
Conv. therm. current
with 5 contacts 6 A 6 A 6 A
Conv. therm. current
with 6 contacts 5,5 A 5,5 A 5,5 A
Conv. therm. current
with 7 contacts 5 A 5 A 5 A
Times 777607 777609 787609
Switch-on delay
With automatic start
typ. 130 ms 200 ms 200 ms
With automatic start
max. 200 ms 250 ms 250 ms
With automatic start
after power on typ. 150 ms 220 ms 220 ms
With automatic start
after power on max. 220 ms 300 ms 300 ms
With manual start typ. 150 ms 200 ms 200 ms
With manual start max. 200 ms 250 ms 250 ms
With monitored start
typ. 100 ms 150 ms 150 ms
With monitored start
max. 150 ms 220 ms 220 ms
Delay-on de-energisation
With E-STOP typ. 20 ms 20 ms 20 ms
With E-STOP max. 30 ms 30 ms 30 ms
With power failure typ. 60 ms 170 ms 170 ms
With power failure max. 80 ms 250 ms 250 ms
Recovery time at max.
switching frequency 1/s
After E-STOP 50 ms 50 ms 50 ms
After power failure 100 ms 300 ms 300 ms
Min. start pulse duration
with a monitored start 30 ms 50 ms 50 ms
Supply interruption before
de-energisation 20 ms 20 ms 20 ms
