Operating Manual PNOZ XV3.1
20515-EN-08
| 19
Relay outputs 774530 774532 774534
External contact fuse pro-
tection, auxiliary contacts
Max. melting integral 240 A²s 240 A²s 240 A²s
Blow-out fuse, quick 10 A 10 A 10 A
Blow-out fuse, slow 6 A 6 A 6 A
Blow-out fuse, gG 10 A 10 A 10 A
Circuit breaker 24 V
AC/DC, characteristic
B/C 6 A 6 A 6 A
Contact material AgSnO2 + 0,2 µm Au AgSnO2 + 0,2 µm Au AgSnO2 + 0,2 µm Au
Conventional thermal
current while loading
several contacts
774530 774532 774534
Ith per contact at UB DC;
AC1:240V,DC1:24V
Conv. therm. current
with 1 contact 8 A 8 A 8 A
Conv. therm. current
with 2 contacts 7,8 A 7,8 A 7,8 A
Conv. therm. current
with 3 contacts 6,5 A 6,5 A 6,5 A
Conv. therm. current
with 4 contacts 5,5 A 5,5 A 5,5 A
Conv. therm. current
with 5 contacts 5 A 5 A 5 A
Times 774530 774532 774534
Switch-on delay
With automatic start
typ. 400 ms 400 ms 400 ms
With automatic start
max. 850 ms 850 ms 850 ms
With automatic start
after power on typ. 400 ms 400 ms 400 ms
With automatic start
after power on max. 870 ms 870 ms 870 ms
With monitored start
typ. 40 ms 40 ms 40 ms
With monitored start
max. 70 ms 70 ms 70 ms
Delay-on de-energisation
With E-STOP typ. 15 ms 15 ms 15 ms
With E-STOP max. 30 ms 30 ms 30 ms
With power failure typ. 110 ms 110 ms 110 ms
With power failure max. 150 ms 150 ms 150 ms
Recovery time at max.
switching frequency 1/s
After E-STOP 50 ms +tv 50 ms +tv 50 ms +tv
After power failure 200 ms 200 ms 200 ms
