Pilz PNOZ XV3.1 User Manual

PNOZ XV3.1
Operating Manual PNOZ XV3.1
20515-EN-08
| 22
Electrical data 774538 774610
Duty cycle 100 % 100 %
Max. inrush current impulse
Current pulse, A1 5 A –
Pulse duration, A1 1 ms –
Inputs 774538 774610
Number 2 2
Voltage at
Input circuit DC 24 V 24 V
Start circuit DC 24 V 24 V
Feedback loop DC 24 V 24 V
Current at
Input circuit DC 50 mA 40 mA
Start circuit DC 40 mA 40 mA
Feedback loop DC 3 mA 3 mA
Max. overall cable resistance Rl-
max
Single-channel at UB DC 100 Ohm 150 Ohm
Single-channel at UB AC – 150 Ohm
Dual-channel with detection of
shorts across contacts at UB DC 10 Ohm 20 Ohm
Dual-channel with detection of
shorts across contacts at UB AC – 20 Ohm
Relay outputs 774538 774610
Number of output contacts
Safety contacts (N/O), instant-
aneous 3 3
Safety contacts (N/O), delayed 2 2
Auxiliary contacts (N/C) 1 1
Max. short circuit current IK 1 kA 1 kA
Utilisation category
In accordance with the standard EN 60947-4-1 EN 60947-4-1
Utilisation category of safety con-
tacts
AC1 at 240 V 240 V
Min. current 0,01 A 0,01 A
Max. current 8 A 8 A
Max. power 2000 VA 2000 VA
DC1 at 24 V 24 V
Min. current 0,01 A 0,01 A
Max. current 8 A 8 A
Max. power 200 W 200 W
