PNOZ XV3P
Operating Manual PNOZ XV3P
20122-EN-05
17
Technical details
Order no. 777510 – 777514
See below for more order numbers
General 777510 777512 777514
Approvals
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
Electrical data 777510 777512 777514
Supply voltage
Voltage 24 V 24 V 24 V
Kind DC DC DC
Voltage tolerance -15 %/+10 % -15 %/+10 % -15 %/+10 %
Output of external
power supply (DC) 4,5 W 4,5 W 4,5 W
Residual ripple DC 160 % 160 % 160 %
Duty cycle 100 % 100 % 100 %
Max. inrush current im-
pulse
Current pulse, A1 5 A 5 A 5 A
Pulse duration, A1 1 ms 1 ms 1 ms
Inputs 777510 777512 777514
Number 2 2 2
Voltage at
Input circuit DC 24 V 24 V 24 V
Start circuit DC 24 V 24 V 24 V
Feedback loop DC 24 V 24 V 24 V
Current at
Input circuit DC 35 mA 35 mA 35 mA
Start circuit DC 50 mA 50 mA 50 mA
Feedback loop DC 3,5 mA 3,5 mA 3,5 mA
Min. input resistance at
power-on 135 Ohm 135 Ohm 135 Ohm
Max. overall cable resist-
ance Rlmax
Single-channel at UB
DC 100 Ohm 100 Ohm 100 Ohm
Dual-channel without
detection of shorts
across contacts at UB
DC 100 Ohm 100 Ohm 100 Ohm
Dual-channel with de-
tection of shorts across
contacts at UB DC 10 Ohm 10 Ohm 10 Ohm
