PSEN cs3.1p/M12
Operating Manual PSEN cs3.1p/M12
1003296-EN-09
| 31
Safety switch PSEN cs3.1 M12/8-1.5m
M12
1500 0+200
48,5
31
19
14,4
4,5
ø 8
14,4
22
37
18 26,4
R 8
18 18
4,5
22
37
Actuator
Actuator PSEN cs1.1
40
11
2 x Ø 5,3
5 30
305
4
Actuator PSEN cs3.1
