Pilz PSEN cs3.1p/M12 User Manual

PSEN cs3.1p/M12
Operating Manual PSEN cs3.1p/M12
1003296-EN-09
| 37
Mechanical data 541059 541060 541064
Min. bending radius (fixed
permanently) K1 5 x Ø 5 x Ø 5 x Ø
Min. bending radius (mov-
ing) K1 10 x Ø 10 x Ø 10 x Ø
Cable diameter K1 5,55 mm 5,55 mm 5,55 mm
Min. distance between
safety switches 100 mm 100 mm 100 mm
Sensor flush installation in
accordance with EN
60947-5-2
Yes, follow installation
guidelines
Yes, follow installation
guidelines
Yes, follow installation
guidelines
Connection type M12, 8-pin male con-
nector
M8, 8-pin male con-
nector
M12, 8-pin male con-
nector
Cable Li9Y11Y 8 x 0,14 mm2 Li9Y11Y 8 x 0,14 mm2 Li9Y11Y 8 x 0,14 mm2
Material
Top PBT PBT PBT
Max. torque setting for fix-
ing screws 0,8 Nm 0,8 Nm 0,8 Nm
Dimensions
Height 37 mm 37 mm 37 mm
Width 26 mm 26 mm 26 mm
Depth 18 mm 18 mm 18 mm
Weight of safety switch 40 g 35 g 100 g
Where standards are undated, the 2016-10 latest editions shall apply.
Technical details actuator
Order no. 540080 - 541080
See below for more order numbers
General 540080 541080
Certifications CE, EAC (Eurasian), TÜV, cULus
Listed
CE, EAC (Eurasian), TÜV, cULus
Listed
Sensor's mode of operation Transponder Transponder
Coding level in accordance with EN
ISO 14119 Low Low
Pilz coding type Coded Coded
Transponder 540080 541080
Frequency band 122 kHz - 128 kHz 122 kHz - 128 kHz
Environmental data 540080 541080
Ambient temperature
In accordance with the standard EN 60068-2-14 EN 60068-2-14
Temperature range -25 - 70 °C -25 - 70 °C
Storage temperature
In accordance with the standard EN 60068-2-1/-2 EN 60068-2-1/-2
Temperature range -40 - 85 °C -25 - 70 °C
