PSEN cs3.1p/M12
Operating Manual PSEN cs3.1p/M12
1003296-EN-09
| 9
For your safety
WARNING!
Loss of safety function due to manipulation of the interlocking device
Manipulation of the interlocking device may lead to serious injury and death.
– You should prevent any possibility of the interlocking device being
manipulated through the use of a spare actuator.
– Keep the substitute actuator in a safe place and protect it from unau-
thorised access.
– If spare actuators are used, these must be installed as described in
Installation [ 22].
– If the original actuators are replaced with substitute actuators, the ori-
ginal actuators must be destroyed before disposal.
} Do not remove the connector's protective cap until you are just about to connect the unit.
This will prevent potential contamination.
Unit features
} Transponder technology for presence detection
} Pilz coding type: Coded
} Dual-channel operation
} 2 safety inputs for series connection of multiple safety switches
} 2 safety outputs
} Safety Device Diagnostics (SDD)
– Safety Device Diagnostics can be used to poll sensor information, to perform actions
and to read configuration parameters
– Manipulation protection in accordance with ISO 14119 is possible by verifying the
short name of the actuator through the controller via SDD communication
} Diagnostic input for Y1 for Safety Device Diagnostics (SDD)
} Signal output/diagnostic output Y32 for Safety Device Diagnostics
} LED display for:
– State of the actuator
– State of the inputs
– Supply voltage/fault
} 1 direction of actuation
} Connection types:
– PSEN cs3.1p: 8-pin M8 male connector
– PSEN cs3.1 M12/8-0.15m: 8-pin M12 male connector, 0.15 m cable
– PSEN cs3.1 M12/8-1.5m: 8-pin M12 male connector, 1.5 m cable
