Technical details safety switch
General 541059 541060 541064
Certifications CE, EAC (Eurasian),
FCC, IC, TÜV, cULus
Listed
CE, EAC (Eurasian),
FCC, IC, TÜV, cULus
Listed
CE, EAC (Eurasian),
FCC, IC, TÜV, cULus
Listed
Sensor's mode of opera-
tion Transponder Transponder Transponder
Coding level in accord-
ance with EN ISO 14119 Low Low Low
Design in accordance with
EN ISO 14119 4 4 4
Classification in accord-
ance with EN 60947-5-3 PDDB PDDB PDDB
Pilz coding type Coded Coded Coded
Transponder 541059 541060 541064
Frequency band 122 kHz - 128 kHz 122 kHz - 128 kHz 122 kHz - 128 kHz
Max. transmitter output 15 mW 15 mW 15 mW
Electrical data 541059 541060 541064
Supply voltage
Voltage 24 V 24 V 24 V
Kind DC DC DC
Voltage tolerance -20 %/+20 % -20 %/+20 % -20 %/+20 %
Output of external
power supply (DC) 1 W 1 W 1 W
Max. switching frequency 3 Hz 3 Hz 3 Hz
Max. cable capacitance at
the safety outputs
No-load, PNOZ with re-
lay contacts 400 nF 400 nF 400 nF
PNOZmulti, PNOZelog,
PSS 400 nF 400 nF 400 nF
Max. inrush current im-
pulse
Current pulse, A1 0,58 A 0,58 A 0,58 A
Pulse duration, A1 1 ms 1 ms 1 ms
No-load current 20 mA 20 mA 20 mA
Inputs 541059 541060 541064
Number 2 2 2
Voltage at inputs 24 V DC 24 V DC 24 V DC
Input current range 5 mA 5 mA 5 mA
Max. overall cable resist-
ance Rlmax
Single-channel at UB
DC 1000 Ohm 1000 Ohm 1000 Ohm
Semiconductor outputs 541059 541060 541064
OSSD safety outputs 2 2 2
Signal outputs 1 1 1
