Pilz PSEN cs3.1p/M12 User Manual

PSEN cs3.1p/M12
Operating Manual PSEN cs3.1p/M12
1003296-EN-09
| 34
Semiconductor outputs 541059 541060 541064
Switching current per out-
put 100 mA 100 mA 100 mA
Breaking capacity per out-
put 2,4 W 2,4 W 2,4 W
Potential isolation from
system voltage No No No
Short circuit-proof yes yes yes
Residual current at out-
puts 20 µA 20 µA 20 µA
Voltage drop at OSSDs 3,5 V 3,5 V 3,5 V
Lowest operating current 0 mA 0 mA 0 mA
Utilisation category in ac-
cordance with EN
60947-1 DC-12 DC-12 DC-12
Times 541059 541060 541064
Test pulse duration, safety
outputs 450 µs 450 µs 450 µs
Switch-on delay
after UB is applied 1 s 1 s 1 s
Inputs typ. 13 ms 13 ms 13 ms
Inputs max. 20 ms 20 ms 20 ms
Actuator typ. 60 ms 60 ms 60 ms
Actuator max. 150 ms 150 ms 150 ms
Delay-on de-energisation
Inputs typ. 15 ms 15 ms 15 ms
Inputs max. 20 ms 20 ms 20 ms
Actuator typ. 40 ms 40 ms 40 ms
Actuator max. 260 ms 260 ms 260 ms
Risk time in accordance
with EN 60947-5-3 260 ms 260 ms 260 ms
Supply interruption before
de-energisation 10 ms 10 ms 10 ms
Simultaneity, channel 1
and 2 max. ∞ ∞ ∞
Environmental data 541059 541060 541064
Ambient temperature
In accordance with the
standard EN 60068-2-14 EN 60068-2-14 EN 60068-2-14
Temperature range -25 - 70 °C -25 - 70 °C -25 - 70 °C
Storage temperature
In accordance with the
standard EN 60068-2-1/-2 EN 60068-2-1/-2 EN 60068-2-1/-2
Temperature range -25 - 70 °C -25 - 70 °C -25 - 70 °C
Climatic suitability
In accordance with the
standard EN 60068-2-78 EN 60068-2-78 EN 60068-2-78
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C 93 % r. h. at 40 °C
