Operating Manual PSEN cs3.1p/M12
1003296-EN-09
| 35
Environmental data 541059 541060 541064
EMC EN 60947-5-3 EN 60947-5-3 EN 60947-5-3
Vibration
In accordance with the
standard EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
Frequency 10 - 55 Hz 10 - 55 Hz 10 - 55 Hz
Amplitude 1 mm 1 mm 1 mm
Shock stress
In accordance with the
standard EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
Acceleration 30g 30g 30g
Duration 18 ms 18 ms 18 ms
Airgap creepage
Overvoltage category III III III
Pollution degree 3 3 3
Rated insulation voltage 75 V 60 V 75 V
Rated impulse withstand
voltage 0,8 kV 0,8 kV 0,8 kV
Protection type
Housing IP6K9K IP6K9K IP6K9K
Connector IP67 IP67 IP67
Operating distances 541059 541060 541064
Actuator 1
Type PSEN cs3.1 PSEN cs3.1 PSEN cs3.1
Assured operating dis-
tance Sao 8 mm 8 mm 8 mm
Typical operating dis-
tance So 11 mm 11 mm 11 mm
Assured release dis-
tance Sar 20 mm 20 mm 20 mm
Typical release dis-
tance Sr 14 mm 14 mm 14 mm
Repetition accuracy
switching distances 10 % 10 % 10 %
Change of operating
distance with temperat-
ure changes +-0,01mm/°C +-0,01mm/°C +-0,01mm/°C
Typ. Hysteresis 2 mm 2 mm 2 mm
