Pilz PSEN cs3.1p/M12 User Manual

PSEN cs3.1p/M12
Operating Manual PSEN cs3.1p/M12
1003296-EN-09
| 44
PSEN cable M8-8sf M8-sm Straight, M8, 8-pin, pin Straight, M8, 8-pin,
socket
0.5 m 533 155
PSEN cable M8-8sf
M8-8sm
1 m 533 156
PSEN cable M8-8sf
M8-8sm
2 m 533 157
Series connection
Product type Connection X1 Connection X2 Connec-
tion X3
Order no.
PSEN Y junction M12
SENSOR
M12, 8‑pin, pin M12, 8-pin, socket M12, 8-
pin,
socket
540 315
PSEN Y junction M12
cable channel
M12, 8‑pin, pin M12, 8-pin, socket M12, 8-
pin,
socket
540 316
PSEN T junction M12 M12, 8-pin, socket M12, 8‑pin, pin M8,
4‑pin, pin
540 331
PSEN Y junction M8-M12/
M12 PIGTAIL
M12, 8-pin, socket M12, 8‑pin, pin M8,
8‑pin,
socket
540 337
PSEN Y junction M12-M12/
M12 PIGTAIL
M12, 8-pin, socket M12, 8‑pin, pin M12, 8-
pin,
socket
540 338
PDP67 F 4 code Decentralised passive junction 773 603
PDP67 F 4 code VA Decentralised passive junction, V2A ring nut 773 613
Safety Device Diagnostics
Product type Features Connection type Order no.
PSENix2F4code Interface for connecting
max. 4 PSEN safety
sensors
Spring-loaded terminal 535 111
PSENix2F8code Interface for connecting
max. 8 PSEN safety
sensors
Spring-loaded terminal 535 112
SDD ES ETH Fieldbus module Modbus/
TCP for Safety Device Dia-
gnostics
Spring-loaded terminal 540 130
SDD ES Profibus Fieldbus module Profibus
for Safety Device Dia-
gnostics
Spring-loaded terminal 540 132
SDD ES Profinet Fieldbus module for Safety
Device Diagnostics
Spring-loaded terminal 540 138
